Acrow® Modular Bridge System

Contact sales
Get technical spec

70m

Maximum Single Span

Few Days

Assembly Time

ISO 9001

Certifiede Quality

Contact an engineer

    Acrow® Modular Bridge System

    The Acrow® bridge system is a modern modular solution inspired by the world-famous Bailey bridge. It is designed for quick installation, long-term durability, and adaptability to almost any site condition. Whether for planned infrastructure or urgent needs, Acrow® bridges provide a safe and efficient way to create crossings that keep traffic and communities moving.

    Technical Excellence

    610 g/m² Premium Materials
    High-strength steel with hot-dip galvanization for superior corrosion resistance.
    Variable Loads Adaptive Load Capacity
    Modify truss configurations and add reinforcing bands to meet specific load requirements.
    Custom Spans Flexible Design
    Panels can be configured to meet specific span lengths, load requirements, and site conditions.
    Download

    Versatile Applications

    Acrow® bridges are designed for maximum flexibility and can be deployed in a wide range of scenarios across various industries and environments.

    Image link
    Temporary Construction Access
    Create service roads and temporary crossings for equipment and workers that can be removed once projects are complete.
    Image link
    Detour Bridges During Repairs
    Act as parallel bypass routes, minimizing traffic disruption, improving worker safety, and accelerating construction schedules.
    Image link
    Permanent Road & Pedestrian Bridges
    High-strength steel design makes it suitable for permanent installations from rural roads to cycling paths.
    Image link
    Emergency & Disaster Relief
    Can be airlifted, assembled by small crews, and launched quickly to reconnect communities and restore supply chains.
    Image link
    Industrial Heavy Haul
    Engineered for extremely heavy loads, providing reliable access for massive mining and logging operations.
    Image link
    Service & Utility Bridges
    Carry pipelines, cables, or critical infrastructure across rivers and obstacles in both urban and remote settings.

    Key Advantages

    Experience the benefits that have made Acrow® the world's most trusted modular bridge solution for decades of successful deployments.

    Fast installation
    Bridges can be built and opened to traffic within days, not weeks
    Reusable
    Designed for multiple assembly and disassembly cycles
    Adaptable
    Easily adjusted to different terrains, spans, and load classes
    Low logistics
    Simple, interchangeable parts that are easy to transport
    No Scaffolding Required
    Complete assembly and disassembly without scaffolding requirements, reducing setup time, costs, and safety risks.
    Reliable in all conditions
    Suitable for year-round use, including winter installations

    System Components

    Engineered for precision and reliability, each component is designed to work seamlessly together for optimal performance and rapid deployment.

    Truss Panels

    218.5 cm × 304.8 cm

    High-strength steel panels with bolted connections for quick assembly and maximum structural integrity.

    Bolted connections
    Hot-dip galvanized
    Quick assembly

    Crossbars (I-profile)

    6 Standard Widths

    Allow for six standard deck widths from 3.65m to 10.96m, spaced every 3.048m along the bridge.

    I-profile design
    3.048m spacing
    3.65m to 10.96m widths

    Deck Options

    Multiple Materials

    Steel plates with optional epoxy coating or wooden deck options, all bolted from above for fast installation.

    Steel plates
    Epoxy coating option
    Wooden deck option

    Walkways

    1.5m Wide

    Cantilevered pedestrian walkways placed outside truss panels for clear separation and increased safety.

    1.5m width
    Cantilevered design
    Safety separation

    Why Choose Acrow®?

    With its modularity, strength, and rapid installation capabilities, the Acrow® 700XS® system is one of the most trusted modular bridge solutions in the world. Whether for planned infrastructure projects or urgent deployments, Acrow® provides a safe, durable, and cost-effective crossing that meets the highest engineering standards.

    Global Presence Worldwide Deployment Proven in Europe and globally
    Decades Of Excellence Trusted engineering heritage
    Contacts

    Quality Certifications

    ISO 9001
    AISC Certified
    CE Mark Europe
